Bend Testing: A Complete Overview

Bend Testing is a quality test that evaluates the mechanical properties of a material by subjecting it to controlled bending forces. Keep reading to know.

Bend testing is a commonly used method to evaluate the mechanical properties of materials, particularly their flexibility and ductility. It involves subjecting a specimen to a controlled bending force and measuring the degree of deformation or fracture that occurs.

In this blog, we will delve into the world of bend testing and explore its various applications, types, and procedures. Keep reading to know!

What Do You Understand By Bend Testing?

Bend testing

Let’s begin with a basic understanding of Bend testing! So, Bend testing, also known as flexure testing or transverse beam testing, examines the performance of materials subjected to simple beam loading. Simply put, a bend test is performed on a universal testing machine at its most basic level by placing a sample on two support anvils and bending it through applied force on one or two loading anvils to measure its properties.

Bend Test: Why Is It Important?

Bend testing plays a crucial role in product quality testing as it enables manufacturers to ensure that their products meet the necessary standards for strength and durability. By subjecting products to controlled bending forces, manufacturers can assess their ability to withstand deformation and failure under stress. This is particularly important in industries such as automotive, where the safety of passengers and drivers depends on the quality and reliability of the products.

For example, bend testing is used to evaluate the strength and durability of automotive components such as chassis frames, suspension systems, and steering linkages. These components must be able to withstand the stresses and strains of everyday use without failing or deforming, which could result in serious accidents.

Bend testing is also important in the manufacturing of consumer products such as furniture and appliances. By subjecting these products to controlled bending forces, manufacturers can ensure that they meet the necessary standards for strength and durability. For example, bend testing can be used to evaluate the strength of chair legs or the flexibility of refrigerator shelves. If these products fail to meet the required standards, they could pose a safety risk to consumers and result in costly recalls for manufacturers.

Overall, without bend testing, it would be difficult to assess the performance of products accurately, which could result in serious safety risks for consumers and costly recalls for manufacturers.

What Are The Important Standards To Be Considered For Bend Test?

Just like dry heat test, light testing, cold test, and IP testing, there are some standards to be considered for bend testing as well. So, let us have a look at some of the most important standards for Bend testing.

  • ASTM E290

This standard covers the testing procedures for determining the ductility of metallic materials using a simple bend test. The standard provides guidelines for specimen preparation, test equipment, test procedures, and data recording.

  • ISO 7438

This International Organization for Standardization (ISO) standard specifies the test method for determining the ductility of metallic materials using a simple bend test. It provides guidelines for specimen preparation, test equipment, test procedures, and data recording.

  • ASME BPVC Section IX

This standard provides the requirements for the qualification of welders, welding operators, brazers, and brazing operators. The standard includes the procedures and acceptance criteria for bend testing of welds.

  • AWS D1.1

This American Welding Society (AWS) standard provides the requirements for welding structural steel components. The standard includes the procedures and acceptance criteria for bend testing of welds.

  • EN ISO 5173

This European standard specifies the test method for determining the ductility of welded joints in metallic materials using a simple bend test. It provides guidelines for specimen preparation, test equipment, test procedures, and data recording.

  • ASTM A370

This ASTM International standard covers a wide range of mechanical testing methods for steel products, including bend testing. The standard provides guidelines for specimen preparation, test equipment, test procedures, and data recording.

  • ISO 15630-1

This ISO standard specifies the test methods for reinforcing steel used in concrete construction, including the bend test. It provides guidelines for specimen preparation, test equipment, test procedures, and data recording.

  • AS/NZS 1554.

This Australian and New Zealand standard provides the requirements for welding steel structures. The standard includes the procedures and acceptance criteria for bend testing of welds.

  • BS EN 10002-1

This British Standard specifies the method for tensile testing of metallic materials at ambient temperature, which includes a bend test as one of the possible test types. The standard provides guidelines for specimen preparation, test equipment, test procedures, and data recording.

These standards ensure that the bend test is carried out consistently and accurately across different laboratories and industries. They also provide a basis for comparing the performance of different materials and welding techniques.

What Is The Complete Procedure Of Bend Test?

Now that you are familiar with the standards for the bend test, let’s move forward toward its procedure. Remember that be it a shock test, oven testing, a solar panel testing, mechanical testing, or bend testing, all of them need to be conducted the right way. This is why we are going to introduce you to the complete procedure of the bend test

Step 1 Sample Preparation

Cut a test specimen from the material being tested to the required dimensions, typically a rectangular shape. The length of the specimen should be at least four times its thickness to ensure an accurate test result.

Step 2 Bend Test Setup

Place the sample on a bend test fixture, which typically consists of two supports separated by a specified distance. The sample should be centered over the supports, with the side to be bent facing upwards.

Step 3 Bend Force Application

Apply a gradually increasing bending force to the sample using a testing machine or manual bending tool. The bending force should be applied at a uniform rate until the sample fractures or reaches the desired degree of deformation.

Step 4 Deformation Measurement

Measure the amount of deformation that occurs during the bending process, typically by recording the angle at which the specimen bends or by measuring the distance between the two supports.

Step 5 Data Analysis

Calculate the bending stress and strain of the sample using the deformation data and the material’s mechanical properties. The results of the bend test can be used to determine the material’s ductility, strength, and other mechanical properties.

Step 6 Record And Report

Record the test data and results obtained from the bend test in a suitable report form that can be used for future reference.

Remember that it’s important to follow the standard test procedures and safety guidelines while performing a bend test to ensure accurate and reliable results.

Why Choose Pride Testing Labs For Bend Testing?

Overall, Bend testing is an indispensable aspect of materials engineering and product quality testing. The ability to evaluate the mechanical properties of materials and products, such as flexibility and ductility, is essential to ensuring the safety and reliability of structures, machinery, and consumer goods. Wait, are you someone looking forward to getting this testing done? If yes, choose us at Pride Testing Labs

At Pride Testing Labs, we recognize the importance of precise and dependable testing procedures and offer a wide range of bend testing services tailored to the specific requirements of our clients. Furthermore, our team of skilled technicians and advanced equipment guarantees accurate and efficient testing procedures, providing our clients with actionable and dependable data.

So, why such a delay? Visit our services page to know more.

×
